PySide6 实操指南：系统页面跳转与控件使用

基本页面跳转实现

在PySide6中实现页面跳转通常有以下几种方法：

1. 使用QStackedWidget

from PySide6.QtWidgets import QApplication, QMainWindow, QStackedWidget, QPushButton, QLabel

app = QApplication([])

# 主窗口
window = QMainWindow()
window.setGeometry(100, 100, 400, 300)

# 创建堆叠窗口部件
stacked_widget = QStackedWidget()
window.setCentralWidget(stacked_widget)

# 页面1
page1 = QLabel("这是页面1")
button1 = QPushButton("跳转到页面2", page1)
button1.move(150, 200)
stacked_widget.addWidget(page1)

# 页面2
page2 = QLabel("这是页面2")
button2 = QPushButton("返回页面1", page2)
button2.move(150, 200)
stacked_widget.addWidget(page2)

# 连接按钮信号
button1.clicked.connect(lambda: stacked_widget.setCurrentIndex(1))
button2.clicked.connect(lambda: stacked_widget.setCurrentIndex(0))

stacked_widget.setCurrentIndex(0)
window.show()
app.exec()

2. 使用单独窗口

from PySide6.QtWidgets import QApplication, QMainWindow, QPushButton, QLabel, QDialog

class SecondWindow(QDialog):
    def __init__(self):
        super().__init__()
        self.setWindowTitle("第二窗口")
        self.setGeometry(200, 200, 300, 200)
        label = QLabel("这是第二个窗口", self)
        label.move(100, 80)

app = QApplication([])

# 主窗口
main_window = QMainWindow()
main_window.setWindowTitle("主窗口")
main_window.setGeometry(100, 100, 400, 300)

button = QPushButton("打开第二窗口", main_window)
button.move(150, 200)
button.clicked.connect(lambda: SecondWindow().exec())

main_window.show()
app.exec()

常用控件使用示例

按钮(QPushButton)

from PySide6.QtWidgets import QPushButton

button = QPushButton("点击我")
button.setStyleSheet("""
    QPushButton {
        background-color: #4CAF50;
        border: none;
        color: white;
        padding: 10px 24px;
        text-align: center;
        font-size: 16px;
        margin: 4px 2px;
        border-radius: 8px;
    }

    QPushButton:hover {
        background-color: #45a049;
    }
""")

# 连接点击事件
button.clicked.connect(lambda: print("按钮被点击了!"))

文本框(QLineEdit)

from PySide6.QtWidgets import QLineEdit

line_edit = QLineEdit()
line_edit.setPlaceholderText("请输入文本...")
line_edit.setStyleSheet("""
    QLineEdit {
        padding: 8px;
        border: 2px solid #ccc;
        border-radius: 4px;
        font-size: 14px;
    }

    QLineEdit:focus {
        border-color: #66afe9;
    }
""")

# 获取文本
text = line_edit.text()

下拉框(QComboBox)

from PySide6.QtWidgets import QComboBox

combo_box = QComboBox()
combo_box.addItems(["选项1", "选项2", "选项3"])
combo_box.setCurrentIndex(0)  # 设置默认选中项

# 获取当前选中项
current_text = combo_box.currentText()
current_index = combo_box.currentIndex()

# 连接选择变化事件
combo_box.currentIndexChanged.connect(lambda index: print(f"选中了第{index+1}个选项"))

表格(QTableWidget)

from PySide6.QtWidgets import QTableWidget, QTableWidgetItem

table = QTableWidget(3, 3)  # 3行3列
table.setHorizontalHeaderLabels(["列1", "列2", "列3"])

# 填充数据
for row in range(3):
    for col in range(3):
        item = QTableWidgetItem(f"数据{row+1}-{col+1}")
        table.setItem(row, col, item)

# 设置样式
table.setStyleSheet("""
    QTableWidget {
        gridline-color: #ddd;
        font-size: 14px;
    }

    QHeaderView::section {
        background-color: #f8f8f8;
        padding: 5px;
        border: 1px solid #ddd;
    }
""")

高级应用：带参数的页面跳转

from PySide6.QtWidgets import (QApplication, QMainWindow, QPushButton,
                              QVBoxLayout, QWidget, QLabel, QLineEdit)

class LoginPage(QWidget):
    def __init__(self, main_window):
        super().__init__()
        self.main_window = main_window
        self.init_ui()

    def init_ui(self):
        layout = QVBoxLayout()

        self.username_input = QLineEdit()
        self.username_input.setPlaceholderText("用户名")

        self.password_input = QLineEdit()
        self.password_input.setPlaceholderText("密码")
        self.password_input.setEchoMode(QLineEdit.Password)

        login_btn = QPushButton("登录")
        login_btn.clicked.connect(self.login)

        layout.addWidget(self.username_input)
        layout.addWidget(self.password_input)
        layout.addWidget(login_btn)

        self.setLayout(layout)

    def login(self):
        username = self.username_input.text()
        password = self.password_input.text()

        # 验证逻辑...
        if username and password:
            self.main_window.show_main_page(username)

class MainPage(QWidget):
    def __init__(self, username):
        super().__init__()
        self.username = username
        self.init_ui()

    def init_ui(self):
        layout = QVBoxLayout()
        welcome_label = QLabel(f"欢迎, {self.username}!")
        layout.addWidget(welcome_label)
        self.setLayout(layout)

class MainWindow(QMainWindow):
    def __init__(self):
        super().__init__()
        self.setWindowTitle("应用演示")
        self.setGeometry(100, 100, 400, 300)

        self.central_widget = QWidget()
        self.setCentralWidget(self.central_widget)

        self.login_page = LoginPage(self)
        self.main_page = None

        self.show_login_page()

    def show_login_page(self):
        self.central_widget.layout = QVBoxLayout()
        self.central_widget.layout.addWidget(self.login_page)
        self.central_widget.setLayout(self.central_widget.layout)

    def show_main_page(self, username):
        if self.main_page:
            self.central_widget.layout.removeWidget(self.main_page)
            self.main_page.deleteLater()

        self.main_page = MainPage(username)
        self.central_widget.layout.addWidget(self.main_page)
        self.central_widget.setLayout(self.central_widget.layout)

app = QApplication([])
window = MainWindow()
window.show()
app.exec()
